Save Manual Operations as automatic plots

The flight path from a manual flight or a manual boundary flight can now be saved as a field with one click for automatic use later. This is helpful for small plots, where you can fly once and save it for repeated use. Pilots can save time on larger plots by manually spraying field boundaries and automatically spraying the rest of the field.

Notes:

  1. The green track on the outermost circle determines the coverage area of the plot. Ensure that the edges of the plot are covered by the green track to avoid omissions.
  2. When using this function to encircle the plot, since the edges have already been sprayed, be sure to edit and adjust the route separately (route spacing, margin, boundary spraying, etc.) to avoid overspraying or missing spots.

Add Marker Lines and Points

When planning flight routes, you can now add marker lines and points to points of interest on the map.

Application Examples:

Marker Lines: Can be used to mark the location of power lines within the plot, making it easier to track their location relative to the drone during operations.

Marker Points: Can be used to mark objects in fields, making it easier to locate and find them quickly after covering the soil.

Notes:

  1. Unlike field boundary points and obstacle points, marker lines and points do not affect route planning or flight operations; they are only used for position display.
  2. Marker lines and points cannot be saved separately. They need to be added to boundary points and saved as a plot.

Low Speed Ascend at the start point

After a refill or battery swap, when the drone returns to the start point or break point, its propeller downwash at low altitude and speed may cause some crops to lodge.

After enabling Low Speed Ascend, the drone can descend and spray from the set Low Speed Ascend height, reducing the risk of lodging.

The start-spraying height is Operation Height plus Low Speed Ascend Height

Note:

  1. Enabling Low Speed Ascend will apply to all turns and starting points (breakpoints). Please use it only where there are no obstacles at the field boundaries and in the field.

Added Route Visualization function in M+ mode

In M+ mode, Route Visualization helps users find the breakpoint and align the drone’s direction according to guidelines. This helps users avoid route deviation and inconsistent spacing.

Note:

  1. To disable this feature, go to “Top Right Corner Settings – Aircraft Settings – Alert and Assist – Route Visualization (M+)” and choose to turn it off.

Task Summary is available in real time during operations

During operations, you can view task summaries in real-time, including completed work data, estimated chemical usage, and the remaining work to be done.

Multi Plot Operations get some optimizations

Multi Plot Operations now supports Empty Tank Point estimation and Automatic RTH.

When using Multitask, Empty Tank Point estimation can now span multiple plots, showing the estimated Empty Tank Point based on the actual volume of chemical left in the tank.

In addition, users can now select “Return Home After Completing Operation” when using Multi Plot Operations. Once enabled, the drone will automatically return to home after completing all plot operations.

Note:

  1. Smart Return to Home supports obstacle avoidance, but the success rate of obstacle avoidance varies with different speeds and obstacles. Please pay attention to the surrounding environment and avoid heights with power lines during return to ensure safety

Introducing Show Fields Nearby to help avoid overlapping

The new “Show Fields Nearby” function helps users avoid overlap by displaying nearby fields on the map during field planning. It also aids in manual operations, helping to avoid accidentally entering adjacent fields.

Spray/Spread When Turning on Orchard Routes

With Spray/Spread When Turning enabled, the drone will continue to spray while turning, improving edge spraying effectiveness.

Note:

  1. This is only effective when the orchard route planning mode is Standard. You can enable it in the remote controller app under “Route Settings – Advanced.”

Additional Updates:

  1. Takeoff is prevented during refilling, enhancing safety for ground crews and operators.
  2. During flight, pilots can press the orange pause button on the remote controller. This will cause the drone to pause automatic flight and enter hover mode.
  3. After landing, propeller rotation stops two seconds faster, increasing safety and reducing downtime.
  4. Added support to perform spreading at the fixed-spot routes in Fruit Tree Operation mode.
  5. Added support to disable atomized spraying in the Fruit Tree Operation mode.
  6. Added support to set the terrain scenario and flight parameters in the Task Settings on the left side of the screen when applying the task.
  7. Optimized the display of the flight trajectory in the app. The flight routes of the latest two flights are shown in the app during the operation.
  8. Added warnings when the propellers are abnormal.

We were excited about the arrival of the latest agricultural drone from the Agras range, the DJI Agras T50, but at the same time we were concerned about what to expect from the new features and overall performance of the drone.
As a leading dealer of agricultural drones, we had the opportunity to work with this drone and test its features for over half a year before its official launch.
In the following articles on our blog we will bring you detailed features, interesting facts, insights and most importantly the results of our field testing of the drone.

Have our fears been confirmed?

Our biggest concern was the change to a magnetic impeller driven pump as well as centrifugal spray nozzles, as we know that the biggest weakness on the previous DJI Agras T30 was the pumps and nozzles.
However, the fears did not come true, the change to this type of spraying system was justified and most importantly significantly more efficient.
The pumps do not come into contact with the spray liquid, which guarantees a longer service life of the pumps as well as a smoother operation of the nozzles.
Centrifugal spray nozzles also impressed us in a positive way, they can handle the application of thicker products, which was a problem with the previous model and which complicated the work of the drone.

New features

In addition to the new spraying system, the Agras T50 differs from previous models with added features.
The most important and most interesting is the mapping function. Thanks to the UHD camera, which has an adjustable angle, it is possible to map fields with the T50 and prepare a mission right in the field. This function is made possible by the new 8-core processor in the remote controller with a 7-inch display.
Compared to the Agras T30, the drone is significantly more agile and the movements during liftoff , return or during a mission are smoother – it feels as if you are controlling the drone even during automatic flight.

Is the 11-meter range realistic in our conditions?

The priority of our testing of the T50 was to see if, in the working conditions in which service providers find themselves, the drone can provide a steady 11-metre sweep and, more importantly, and even coverage of crops.
As is our custom in coverage testing, the testing was done under realistic conditions, with indicator papers and a number of combinations that can occur on the job.
The DJI Agras T50 did not disappoint, the 11-meter range is a reality and the coverage, which is the most important factor, is achieved. However, we will bring you a detailed analysis of our testing in future articles, as there are combinations of speed – droplet size – dose – width of coverage, which we prefer to avoid.

Conclusion

The DJI Agras T50 is the drone we’ve been waiting for. Not so much the increased tank volume as the amount of new features this model has brought us. The new features will guarantee you the efficiency and speed to get that promised 21 hectares per hour – yes, it’s possible.
We will bring you a more detailed analysis of the features and our testing in the following articles that we will prepare for you. Don’t hesitate to subscribe to our newsletter so that you don’t miss out on important information that could make your work more pleasant and easier in the future.

Already in 2019, we have encountered many complications and problems when entering the Slovak market with the provision of agrodrone services in agriculture. As the market was not and still is not fully accustomed to such technology in agriculture, one of these problems was the clientele and getting orders for these services. It is for this reason that we know what obstacles start-up entrepreneurs in this field have to go through. That’s why with our latest product, we decided to help everyone to have not only a start but also a whole “service career” much easier than we had it.

Access to contracts even without clients

The product that we want to introduce to you with this article is our BIRDU web portal. BIRDU is a portal that serves both service providers and service providers.

The idea of the portal is to make it possible for a new provider of these services, who is new to agriculture, for example, has no contacts, does not know how to get clients for these services, to get orders. Therefore, any customer who is interested in agrodron services can register on our portal and place a request for each application they are interested in, which can then be accessed by any service provider (sprayer). Thus, registered sprayers will be able to see every order from clients in their area (or an area they can determine in advance).

The customer enters, the service provider accepts

When entering the portal, the registered customer has the option to create a new order. When creating an order, it is necessary to choose the date period when he would be interested in the application agrodronmi. After selecting the date period, it is also necessary to select the specific parcel for which the order is created. This selection can be made on the map which will be displayed to the customer immediately after clicking on “new order”.

Then, when the customer has filled in the necessary information, he can choose the publication of the order from two options:

The customer has the option to choose to publish the order to the public, thus making the order available to every registered service provider in their area and thus ensuring a higher chance of the order being accepted by one of the many service providers or a particular service provider they may have been working with for a long period of time. The service provider then accepts the order and issues a quotation, which the client may or may not accept.

Weather

When ordering, it is also possible to monitor the weather for each day. If the customer has entered a date period in which they report unsuitable weather on the application, the sprayer can request a change to a date period specified by them. Thus, the weather feature can help avoid potential complications and delays on the part of the service provider.

More agrodrones, more pilots, more teams

After registration, the registered service provider must also add a list of drones with pilots to their profile in order to be able to subsequently create a team that will be assigned to individual orders. When creating teams, the service provider first enters the number of agrodrones he has: the name of the drone and its serial number. Once the agrodrones have been entered, each pilot must also be entered: the name of the pilot and his average output per day and night (in hectares).

When the service provider enters the necessary information, he can create teams: the name of the team and also assign the pilot and agrodrone he wants to have in this team. More agrodrones, more pilots and more teams will of course give you more efficiency and more hectares flown.

Sub-order or postponement

If the deadline does not suit you as a service provider, you have the option of postponing or creating a sub-order on the portal.

Postponement means that if you are unable to execute an order you have the option of postponing it to another service provider, who will then invoice themselves once it has been executed.

However, if you have some partners who will execute the order on your behalf, for your client – you can create a sub-order. A sub-order is a feature in which your partner (the service provider you are working with) creates a quote for you and you, as the service provider, create a quote for the customer who has selected you for their order. In this function, the executor for the customer is retained, who will also invoice the order. But the executor will order their service provider to do the work.

Partner -> your company -> customer

This model is mainly used in case of congestion and with regular clients who are a priority for you.

Conclusion

To make working with the portal as easy as possible for you, we have prepared a video tutorial containing all the necessary functionalities and procedures for working with the portal.

You can watch the video on our website or YouTube channel.

In order to keep innovating and to attract as many people as possible in different sectors, not only in agriculture and industry, but also the general public, we try to invent and bring new products to our offer, which would have a use for example in travel, sports, fishing, etc..

As the exclusive and only dealer in the country, we bring to the market “Deeno”, a brand offering portable (electric) charging stations and solar panels.

If you work remotely, camp, go fishing or if the power is out at home, having access to a portable power source can help you significantly – that’s why we have decided to add similar products to our offer.

So what is Deeno?

Enterra Deeno X1500 portable charging station

In our range you’ll currently find the Deeno X1500 which is a portable charging station designed to fill the role for your off-grid adventures.

The big benefit is the high power capacity that this station offers. With a capacity of 1036 Wh and a power output of 1500 Watts, it can handle the demands of most home appliances.

When it comes to charging smartphones, laptops, or if you need to run your microwave or blender urgently – the Deeno X1500 can help you with that.

LiFePO4

The station is equipped with state-of-the-art LiFePO 4 technology, which ensures stability and efficiency in power supply. Lithium iron phosphate batteries have high energy density and low self-discharge values. One of the most important features of this type of battery is an electronic management system called BMS, which controls not only the charging and discharging of the battery, but also its temperature.

Thanks to this advanced technology, the station guarantees the endurance, reliability and stability you need for outdoor activities.

Practical design

Miroslav Baca with Deeno X1500 charging station from Enterra company

The importance of user comfort is also ensured by the practical design that the Deeno X1500 offers. All input and output ports are easily accessible and labelled. Hidden handles make it easy to carry and transport the station so that you can get on your adventures without any hassle.

Features and amenities

LED light on the back of the station provides 4 modes of operation – 25%, 50%, 100% and SOS mode. In addition to the light, you also have a clear 4.3-inch LCD display that provides real-time information on power status, power, and time remaining.

A great advantage of this station is also the solar charging option – the optional portable solar panel uses the MTTP function and can charge the station in 6 hours.

Where can Deeno be used?

Miroslav Baca testing Deeno X1500 charging station from Enterra company using angle grinder
Miroslav Baca charging his iPhone with Deeno X1500 charging station from Enterra company
